Descriptions:
The CMX Audio IP-600RM IP Network Paging Microphone or IP paging console or IP paging station is used to paging over network to remote speaker zones. This paging microphone could be installed to anywhere of the LAN system. The IP network paging microphone has several paging modes include: zone paging, group paging, all zone paging, two way intercom, conference system, discussion system & voting system. The IP network paging microphone is built-in a LCD to display program status and its IP address, end-user is accessible to change the IP setting with password. It is built-in a 1W speaker with excellent sound clearance so as to ensure the communication is smooth and clear. This microphone design is adopted advanced technology to avoid echo noise and to avoid data delay as well.
Features:
- Desktop IP paging microphone, with exquisite appearance, elegant craft and modern design.
- Full duplex two way communication from any point to another intercom system.
- Embed PC technology, built-in DSP and high speed industrial chip to ensure start time less than 1 second.
- With 3.4 inch LCD user-friendly human-machine interface.
- With numeric keys, functional keys to call any terminal, easy to operate.
- One button push to answer intercom system.
- Several paging capacity: zone paging, group paging, all zone paging, two way intercom.
- Network conference system solution of discussion and voting function.
- Intercom inquiry with chime warning tone and flashing indicator.
- Support infrared remote control receiver, with a remote controller to complete all operations.
- Built-in 2W full-range monitor speakers with clear voice restoration and no echo noise.
- Support hands-free call and program broadcast receiving.
- With earphone or headphone input for monitor or communication.
- Within one external microphone input and one aux output for sound system.
- 24V DC power supplied, the power adapter is included in the packaging.
Specifications:
| Model | IP-600RM |
| Description | IP Network Paging Microphone |
| Network Input | Standard RJ45 |
| Communication Protocol | TCP/IP, UDP, IGMP |
| Audio Format | MP3/MP2 |
| Sampling Rate | 8K~48KHz |
| Transmission Speed | 10M/100Mbps |
| Audio Mode | 16 digit stereo CD sound quality |
| Frequency Response | 20Hz~16KHz (+1dB, -3dB) |
| T.H.D. | ≤0.3% |
| S/N Ratio | >70dB |
| Built-in monitor speaker | 4 ohm, 2W |
| Aux Input | 350mV Industry-standard voltage wire terminals |
| Aux Output | 1V Industry-standard voltage wire terminals |
| Aux Output Impedance | 1KΩ |
| Microphone impedance | 10mV |
| Working temp | 5 ℃~ 40℃ |
| Humidity | 10% ~ 90% |
| Power Consumption | ≤10W |
| Power Supply | DC 24V |
| Dimensions | 200x145x48.5mm |
| Weight | 0.5Kg |
