Tabletop mixer amplifier with media player
Built-in medial player with USB/SD, FM/DAB+ & Bluetooth
Rated power output at 30W, 60W to 120W
Speaker output of 100V or 70V & 4-16Ω
3 x mic/line inputs, 2 x RCA line inputs, 1 x TEL input and 1 x RCA line output
XLR input with switchable +48V phantom power
With short-circuit, clip, overload and high temp protection
230V AC and 24V DC both power supply
Specification:
| Model | AX-60E | ||
| Description | Tabletop Mixer Amplifier with USB/SD & FM/DAB+ & Bluetooth | ||
| Rated Power Output | 60W | ||
| Speaker Outputs | 100V or 70V & 4-16Ω | ||
| Connector | Mic1 input by balanced XLR with phantom power
Input2-3 inputs Mic/Line switchable unbalanced 6.3mm jack Line1-2 inputs by RCA, Tel input with MOH, Line output by RCA |
||
| Input | Mic1-3: 5-8mV, 600Ω; Line & TEL: 150-470mV, 10KΩ, unbalanced RCA | ||
| Line Out | 0.775(0dBV) | ||
| Frequency Response | 60Hz-15kHz(±3dB) | ||
| S/N Ratio | Line ≥ 85dB, Mic≥ 72dB | ||
| Weight | 4.3kg | ||
